bc-4000

BC-4000 Finishing Teeth

Click a number on the diagram to find the part.

Ref	Part #	Description	Qty	Price
1	BCP-129	PLATE	1	$8.79
2	BCP-130COM	BRUSH CRUSHER UNIT - BC-4000 ONE SIDE	1	$1,583.79
3	BCP-130AS-L	LINKAGE ASSEMBLY-LEFT	1	$369.56
4	BCP-130AS-R	LINKAGE ASSEMBLY-RIGHT	1	$369.56
5	BCP-135AS	LINKAGE ASSEMBLY	2	$49.89
6	BCP-136AS	TOOTH ASSEMBLY	1	$365.72
7	BCP-139AS	SMALL LINK ASSEMBLY	2	$49.88
8	BCP-140AS	TOOTH ASSEMBLY	1	$433.68
9	BCP-142AS	SLEEVE	1	$314.19
10	BCP-145AS	PIN	1	$40.22
11	BCP-148AS	PIN ASSEMBLY	1	$58.64
12	BCP-149	PIN	1	$55.35
13	BCP-150	PIN	1	$34.46
14	SR-C08	SNAP RING - EXTERNAL	8	$5.03
15	SR-C10	SNAP RING - EXTERNAL	4	$5.03
16	CBF1011064	CARRIAGE BOLT - 5/8 X 4	1	$12.58
17	HFN1011	NUT - 5/8	1	$1.26
18	QLP0400028	LYNCH PIN	1	$5.03
19	ZER1805	GREASE FITTING	14	$2.53
20	HAR-05	HAIR PIN	1	$0.89

Click a number on the diagram to find the part.

Ref	Part #	Description	Qty	Price	Buy
1	BCP-232AS	SLEEVE	1	—	Call to order
2	CBT1011056	CARRIAGE BOLT -5/8 X 1/2	1	—	Call to order
3	HFN1011	NUT - 5/8	1	$1.26
4	ZER1805	GREASE FITTING	2	$2.53

Click a number on the diagram to find the part.

Ref	Part #	Description	Qty	Price	Buy
1	BCP-230AS	SLEEVE	1	—	Call to order
2	BCP-231	TIE PLATE	1	—	Call to order
3	BUS-176	BUSHING	2	$30.17
4	HHS0813020	BOLT - 1/2 X 1-1/4	4	$2.53
5	CBT1011056	CARRIAGE BOLT -5/8 X 1/2	1	—	Call to order
6	LWM08	LOCK WASHER - 1/2	4	$0.37
7	HFN0813	NUT - 1/2	4	$0.95
8	ZER1805	GREASE FITTING	2	$2.53
9	HFN1011	NUT - 5/8	1	$1.26
